23kCT/150+150 ohm Output Transformer for driving a balanced line from push-pull 6CG7 etc. 100% M6 core for high level capability and low distortion. Twin secondaries for 600/150 ohm outputs. Voltage ratio 12.4CT:1+1 Max dc per side of primary 20 mA. Similar to Peerless 16402. Colour coded leads. Supplied with end frames for vertical or horizontal mounting style o. Fully shrouded style “s” option. Rectangular Mumetal Can with threaded grommet style “e” option.
Sowter 1232 Output Transformer
£101.18
Altec 436C Line Output Transformer.
| Weight | 0.65 kg |
|---|---|
| Size | K |
| Order lead time | 6 weeks order time / Available on request |
| Minimum order quantity | 1 |
| PDF Data Sheet Link | https://virtualdesigncloud-test.co.uk/wp-content/uploads/2023/07/1232.pdf |
| Package Types | A, O, S |
