15k/185 ohm output transformer for driving a balanced ohm line from push-pull 6SN7, ECC83 etc. 50% Mumetal core for high bandwidth and dynamic range, Max output level at 50 Hz +28 dBu (19 volts). Includes primary taps for UA 176. Total dc resistance ref secondary 14 ohms. Colour coded leads. Pro Audio size K
.
Sowter 1285 Output Transformer
£149.56
UA-176 Push-Pull Output Transformer triode to balanced line 9CT:1 with attenuator.
| Weight | 0.72 kg |
|---|---|
| Size | K |
| Order lead time | 6 weeks order time / Available on request |
| Minimum order quantity | 1 |
| PDF Data Sheet Link | https://virtualdesigncloud-test.co.uk/wp-content/uploads/2023/07/1285.pdf |
| Package Types | A, S, E |
